商品編號:US16x08

商品編號:US16x08

Tascam US-16x08 USB錄音介面 原廠公司貨【US16x08】

TWD $16,250

TWD $12,500

-請選擇-
運送&付款
  • 一般宅配
  • 貨到付款
  • 轉帳匯款
  • 宅配代收
  • LINE Pay
  • 信用卡
  • 分享商品到

商品詳情


Tascam US-16x08 USB錄音介面 原廠公司貨【US16x08】
▲數位混音器/錄音介面兩用,CP值高的 Tascam 16x08!
TASCAM US-16x08 USB 錄音介面,專門設計給需要應付各種情況的錄音工作者,擁有八個麥克風輸入加上各八個 TS 輸入與輸出。機上的 MIDI I/O 介面可連接 keyboard 或其他控制器。而機上的 DSP ,則可以在機上處理簡單的效果器,讓錄音時達到更短的延遲,更加的順暢。TASCAM US-16x08 可跨平台不管在 Mac、PC 甚至行動裝置上,皆可做使用。
▲特色:
-16-in/16-out USB 2.0 錄音介面
-數位 Mixer 且內含 EQ 與 Compressor 效果器
-最高 24-bit/96kHz 解析度
-包含 XLR/TRS 分別 Mic/Line 輸入
-知名 NE5532 op-amp 擴大器
-鋁合金架高設計
-Ultra-HDDA 麥克風前級
-5-Pin DIN MIDI I/O
-Mac, Windows, iOS 可使用
▲規格:
Sampling frequency:44.1k/48k/88.2k/96k Hz
Quantization bit rate:16/24-bit

MIC IN(IN 1-8)
Connector:XLR-3-31 (1: GND, 2: HOT, 3: COLD), BALANCED
Input impedance:2.4kΩ
Nominal input level
GAIN: MAX:–68dBu (0.0003Vrms)
GAIN: MIN:–12dBu (0.195Vrms)
Maximum input level:+8dBu (1.947Vrms)
Gain:56dB

INST IN (IN 9-10)
Connector:1/4" (6.3mm) TS-jack (T: HOT, S: GND), UNBALANCED(when set to "INST" at LINE/INST switch)
Input impedance:1MΩ or more
GAIN: MAX:–57dBV (0.0014Vrms)
GAIN: MIN:–12dBV (0.251Vrms)
Maximum input level:+8dBV (0.2512Vrms)
Gain:45dB

LINE IN (IN 9-10)
Connector:1/4" (6.3mm) TRS-jack (T: HOT, R: COLD, S: GND), BALANCED(when set to "LINE" at LINE/INST switch)
Input impedance:10kΩ
GAIN: MAX:–41dBu (0.0069Vrms)
GAIN: MIN:+4dBu (1.228Vrms)
Maximum input level:+24dBu (12.182Vrms)
Gain:45dB

LINE IN (IN 11-16)
Connector:1/4" (6.3mm) TS-jack (T: HOT, S: GND), UNBALANCED
Input impedance:10kΩ or more
Nominal input level:–10dBV (0.3162Vrms)
Maximum input level:+10dBV (3.162Vrms)
Connector:1/4" (6.3mm) TRS-jack (T: HOT, R: COLD, S: GND), BALANCED
Input impedance:10kΩ
Nominal input level:+4dBu (1.228Vrms)
Maximum input level:+24dBu (12.182Vrms)

LINE OUT (LINE OUT 1-8)
Connector:1/4" (6.3mm) TRS-jack (T: HOT, R: COLD, S: GND), BALANCED
Output impedance:100Ω
Nominal output level:+4dBu (1.228Vrms)
Maximum output level:+24dBu (12.177Vrms)

PHONES
Connector:1/4" (6.3mm) stereo phone jack
Maximum output level:70mW + 70mW or more (THD+N 0.1% or less, 32Ω loaded)
Output impedance:51.5Ω
Working impedance:16Ω to 600Ω

MIDI IN / OUT
Connector:DIN 5-pin
Format:Standard MIDI format

USB
Connector:USB B type 4-pin
Format:USB2.0 HIGH SPEED mass storage class

Power:Dedicated AC adapter (GPE248-120200-Z, included)
Power consumption:12W
Dimensions (W×H×D):17.5" × 2.32" × 8.62" / 445 × 59 × 219 mm
Weight:6.11 lbs. / 2.8 kg
Operating temperature:41˚F to 95˚F / 5˚C to 35˚C
Accessories:Rack mount adapter, USB cable, User's manual, warranty card, dedicated AC adapter (GPE248-120200-Z)

Audio performance
LINE OUT(BALANCED)
44.1k/48k Hz:20Hz to 20kHz, ±0.3dB(JEITA)
88.2k/96k Hz:20Hz to 40kHz, ±0.3dB(JEITA)
THD:0.008% or less
S/N ratio:100dB or more
Crosstalk:100dB or more
EIN:–125dBu or less
